    9109044 Parker Pneumatic Air Bellows 9109 Air Shock Suspension Dunlop 12''×1

    Ask Lasest Price
    Brand Name : AIRSUSTECH
    Model Number : 1B12×1P
    Certification : ISO/TS16949:2009
    Price : Negotiable
    Payment Terms : T/T, Western Union, Paypal or Others
    Supply Ability : 1000PCS/Week
    Delivery Time : 5-8 Working Days
    • Product Details
    • Company Profile

    9109044 Parker Pneumatic Air Bellows 9109 Air Shock Suspension Dunlop 12''×1

    9109044 Parker Pneumatic Air Bellows 9109 Air Shock Suspension Dunlop 12''×1


    Product Description


    Air bellows are the ideal choice for applications requiring short stroke, high thrust single acting actuators. Manufactured from fabric reinforced synthetic rubber in one, two or three convolutions according to stroke and model. They incorporate no reciprocating metal parts and so provide virtually frictionless thrust compared with conventional pneumatic cylinders.


    Product Specifications


    Type12''×1
    Height MIN.50 mm
    Height MAX.150 mm
    Static Height100 mm
    Max Stroke100 mm
    Bellow Max. Diameter305 mm
    Space Required330 mm
    Top/Bottom Cover Plate Diameter260 mm
    Screw Center Distance232 mm
    Screw TypeM10
    Air SizeG 1/2
    Max. Pressure8
    Weight5.2 kg

    Cross References


    Parker

    9109044

    Firestone

    W01-R58-4060, W01 R58 4060, W01R584060, WO1-R58-4060, WO1 R58 4060, WO1R584060

    Dunlop Pneuride

    12''×1, 12'×1, 12×1

    Dunlop Springride

    SP1540, SP 1540

    Contitech

    FS 412-10 DS, FS 412 10 DS, FS412-10 DS, FS412-10DS, FS 41210 DS, FS 41210DS, FS412-10DS, FS41210DS

    Norgren

    PM/31121, PM31121, PM31121


    Main data


    • 10 sizes, diameters 70-660 mm (i.e. 2¾"-26")

    • Strokes from 65 to 430 mm

    • Single, double or triple convolutions

    • Angular misalignment: 15° max.

    • Axial misalignment: 10 mm max.

    • High thrust and frictionless movement

    • Maintenance free


    Air Bellows Characteristics


    1. Air bellows are the ideal choice for applications requiring short stroke, high thrust single acting actuators.
    2. Manufactured from fabric reinforced synthetic rubber in one, two or three convolutions according to stroke and model.
    3. They incorporate no reciprocating metal parts and so provide virtually frictionless thrust compared with conventional
    4. pneumatic cylinders.
    5. All models are single acting only. The return stroke is provided in part by the natural spring action of the bellows but more usually by the load itself.
    6. The simplicity of construction provides an extremely long, virtually maintenance-free service life even under arduous
    7. conditions.
    8. Air bellows are suitable for vibration applications i.e. device feeders at high frequency

    1B12×1P The Real Pictures
