    Norgren Air Bellow M/31081 Total Stroke Height 80MM Pneumatic Norgren Cylinder

    Ask Lasest Price
    Brand Name : AIRSUSTECH
    Model Number : 1B8×1T
    Certification : ISO/TS16949:2009
    Price : Negotiable
    Payment Terms : T/T, Western Union, Paypal or Others
    Supply Ability : 1000PCS/Week
    Delivery Time : 5-8 Working Days
    • Product Details
    • Company Profile

    Norgren Air Bellow M/31081 Total Stroke Height 80MM Pneumatic Norgren Cylinder

    Norgren Air Bellow M/31081 Total Stroke Height 80MM Pneumatic Norgren Cylinder


    Product Description


    Air springs are extremely durable, precisely engineered, and cost-effective for a variety of actuation and vibration isolation applications. With their proven design, fabric-reinforced neoprene or natural rubber flex member construction, and corrosion-resistant end retainers, air springs offer superior quality and performance. As isolators, air springs effectively reduce the harmful effects of vibration. They can simultaneously isolate vibration and adjust load height, allowing for consistent vibration isolation at varying loads.


    Product Specifications


    • Air Inlet/Air Hole/Gas Hole

    Air Fitting: G 1/2

    Operation: Gas-filled


    • Nuts/Screw Type

    Distance Air Hole Betweeen Screw: 78 mm

    Screw Center Distance: 156 mm

    Screw Bolts Height: 25 mm


    • Cover Plate

    Top Cover Plate Diameter: 184 mm

    Bottom Cover Plate Diameter: 184 mm


    • Height

    Minimum Height: 50 mm

    Maximum Height: 130 mm

    Design Height: 90 mm

    Total Sroke Height: 80 mm


    • Rubber Bellows

    Installation Diameter: 245 mm

    Bellow MAX. Diameter: 230 mm


    Technical Data


    ModelM/31061M/31062M/31081M/31082M/31101M/31102M/31103M/31121M/31122
    Cylinder [inch]6''6''8''8''10''10''10''12''12''
    Port sizeG 1/2G 1/2G 1/2G 1/2G 1/2G 1/2G 1/2G 1/2G 1/2
    Nominal (inch)×convolutions6''×16''×28''×18''×210''×110''×210''×312''×112''×2
    Stroke [mm]5511575175100225330100225
    Installation height min [mm]5075507550751005075
    Recommed max working height [mm]95170115220135245350135245
    Installation height max [mm]105190130250150300430150300
    Retracting force to rech min height [N]140220220350150150250200250

    Cross References


    Contitech

    FS 138-8 DS, FS 138 8 DS, FS1388DS, FS 138-8DS

    FS 1388DS, FS 138 8DS, FS138-8 DS, FS138 8 DS

    Dunlop SpringrideSP1537, SP 1537

    Firestone

    W01-R58-4054, W01 R58 4054, W01R584054

    WO1-R58-4054, WO1 R58 4054, WO1R584054

    Dunlop Pneuride

    8''×1

    Norgren

    M/31081, M31081, M 31081

    Parker

    9109014


    Specification


    ♦Install
    Although they serve similar functions, air springs are much less expensive than air cylinders and other springs. When deflated, air springs have a small footprint and are easy to handle and connect to machinery.

    Maintain
    Maintenance procedures for air springs tend to be minimal, air springs require no lubrication, and there are no seals or guides that can become misaligned or damaged like other springs. Air springs should be stored at room temperature in a dry, dark place.

    Environment
    Due to their durability and simplicity, air springs are suitable for most industrial and commercial applications. Rubber and neoprene are prone to dry rot, so dehumidified conditions can shorten the life of an air spring.

    Medium
    Air spring bellows can also accept other types of fluids such as nitrogen, carbon, water and antifreeze.


    The Real Pictures of 1B8×1T
