EI Ride 8030190 Industrial Air Spring Suspension Firestone W01-358-7180 Style 22

Guangzhou Guomat Air Spring Co., Ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now
    Buy cheap EI Ride 8030190 Industrial Air Spring Suspension Firestone W01-358-7180 Style 22 from wholesalers

    Buy cheap EI Ride 8030190 Industrial Air Spring Suspension Firestone W01-358-7180 Style 22 from wholesalers
    • Buy cheap EI Ride 8030190 Industrial Air Spring Suspension Firestone W01-358-7180 Style 22 from wholesalers
    • Buy cheap EI Ride 8030190 Industrial Air Spring Suspension Firestone W01-358-7180 Style 22 from wholesalers
    • Buy cheap EI Ride 8030190 Industrial Air Spring Suspension Firestone W01-358-7180 Style 22 from wholesalers
    • Buy cheap EI Ride 8030190 Industrial Air Spring Suspension Firestone W01-358-7180 Style 22 from wholesalers

    EI Ride 8030190 Industrial Air Spring Suspension Firestone W01-358-7180 Style 22

    Ask Lasest Price
    Brand Name : AIRSUSTECH
    Model Number : 2B6330
    Certification : ISO/TS16949:2009
    Price : Negotiable
    Payment Terms : T/T, Western Union, Paypal or Others
    Supply Ability : 1000PCS/Week
    Delivery Time : 5-8 Working Days
    • Product Details
    • Company Profile

    EI Ride 8030190 Industrial Air Spring Suspension Firestone W01-358-7180 Style 22

    EI Ride 8030190 Industrial Air Spring Suspension Firestone W01-358-7180 Style 22


    2B6330 Specifications


    Air Hole/Air Fitting

    Gas Hole: 1/4 NPTF

    Operation: Gas-filled


    Height

    Maximum Height: 305 mm

    Miinmum Height: 81 mm

    Stroke Height: 224 mm


    Rubber Bellows

    Bellow Max. Diameter: 325 mm

    Structure: Double convoluted

    Bumper: No


    Cover Plate

    Bottom Cover Plate Diameter: 231 mm

    Top Cover Plate Diameter: 231 mm


    Nuts/Screw

    Screw Center Distance: 157 mm

    Distance Gas Hole Between Nut: 71 mm


    Cross References


    Firestone

    W01-358-7180, W013587180, W01 358 7180

    WO1-358-7180, WO13587180, WO1 358 7180

    W01-358-7122, W013587122, W01 358 7122

    WO1-358-7122, WO13587122, WO1 358 7122

    Contitech

    FD 330-22 363, FD 330 22 363, FD33022363

    FD 33022 363, FD 33022363, FD330-22 363

    FD330 22 363, FD33022 363, FD33022363

    FD 33022 363, FD330-22363, FD 330-22363

    Goodyear

    2B12-425/311, 2B12 425/311, 2B12425/311

    Triangle

    6316/4363

    Airkraft115061/3B-356
    VibracousticVSP2B22R7180
    EI Ride8030190
    LelandSc2075
    Navistar1685179C1
    Hendrickson1VA1816
    Ridewell1003587180C
    SAF Holland57007180
    Watson & ChalinlAS0154 1G/01881F, AS01541G/01881F
    Peerless0550 00001

    Style 22, We Can Supply Other Models


    Blind nuts, 1/4 NPT

    W01-358-7180, W013587180, W01 358 7180

    WO1-358-7180, WO13587180, WO1 358 7180

    W01-358-7122, W013587122, W01 358 7122

    WO1-358-7122, WO13587122, WO1 358 7122

    Blind nuts, 1/4 NPT, bumper

    W01-358-7400, W01 358 7400, W01 358 7400 WO1-358-7400, WO1 358 7400, WO13587400

    Blind nuts, 3/4 NPT

    W01-358-7184, ​W01 358 7184, ​W013587184

    WO1-358-7184, WO1 358 7184, WO13587184

    Blind nuts, 3/4 NPT, bumper

    W01-358-7185, W01 358 7185, W013587185

    WO1-358-7185, WO1 358 7185, WO13587185

    Countersunk steel bead rings, 15/8 bolts, nuts, washers

    W01-358-7431, W01 358 7431, W013587431

    WO1-358-7431, WO1 358 7431, WO13587431

    Rubber bellows only

    W01-358-0226, ​W01 358 0226, ​W013580226

    WO1-358-0226, WO1 358 0226, WO13580226


    Company Profile


    • Guangzhou Guomat air spring Co.,Ltd. is located in China's first open ports -- Guangzhou, from the Guangzhou Baiyun International Airport only fifteen minutes by car. Our factory has an area of about 20,000 square meter sand is modernly buil twith advanced rubber air spring manufacturing equipment. Is currently China's largest production base of airspring.
    • Our products are mainly used in commercial vehicles,track vehicles,industrial machinery equipment base. The main products are: rubberairspring, passenger car truck airbag, airbag, paper making machinery industry with the air spring, large washing machine, automotive rubber air spring, now has hundreds of models and styles ,but also according to customer requirements or customer's existing product specifications to design and production, welcome new and old customers call advisory.
    • Our company adopts the most advanced domestic air spring dedicated processing equipment and the introduction of foreign production technology of air spring Combined with our unique production process, in accordance with international standardsofproduction,tocreateaworld-classproducts.

    The Related Pictures of 2B6330:
