    Airkraft 115061/3B-356 Air Spring Assembly Style 22 Double Convoluted Bellows

    Ask Lasest Price
    Brand Name : AIRSUSTECH
    Model Number : 2B6330
    Certification : ISO/TS16949:2009
    Price : Negotiable
    Payment Terms : T/T, Western Union, Paypal or Others
    Supply Ability : 1000PCS/Week
    Delivery Time : 5-8 Working Days
    • Product Details
    • Company Profile

    Airkraft 115061/3B-356 Air Spring Assembly Style 22 Double Convoluted Bellows

    Airkraft 115061/3B-356 Air Spring Assembly Style 22 Double Convoluted Bellows


    Product Specifications

    Air Fitting
    1/4 NPTF
    Number of Ply BellowsDouble
    Minimum Usable Height81 MM/3.2 in.
    Max Expanded Height305 MM/12 in.
    Stroke Height224 MM/8.8 in.
    Threaded Hole
    2X3/8-16UNC
    Top/Bottom Cover Plate Diameter231 MM/9 in.
    Hole/Stud QtyTwo On One Plate
    Screw Center Distance157 MM/6.2 in.
    Distance Gas Hole Between Nut73 MM/2.88 in.
    Bellow Max. Diameter325 MM/12.9 in.

    Technical Parameters


    Force @ 20 PSIG at design height (pounds): 1,430

    Force @ 40 PSIG at design height (pounds): 2,900

    Force @ 60 PSIG at design height (pounds): 4,390

    Force @ 80 PSIG at design height (pounds): 5,950

    Force @ 100 PSIG at design height (pounds): 7,450


    Volume @ 100 PSIG(in3) at 10 in.: 809

    Volume @ 100 PSIG(in3) at 9 in.: 752

    Volume @ 100 PSIG(in3) at 8 in.: 685

    Volume @ 100 PSIG(in3) at 7 in.: 610

    Volume @ 100 PSIG(in3) at 6 in.: 529

    Volume @ 100 PSIG(in3) at 5 in.: 442

    Volume @ 100 PSIG(in3) at 4 in.: 349

    Cross References


    Firestone

    W01-358-7180, W013587180, W01 358 7180

    WO1-358-7180, WO13587180, WO1 358 7180

    W01-358-7122, W013587122, W01 358 7122

    WO1-358-7122, WO13587122, WO1 358 7122

    Contitech

    FD 330-22 363, FD 330 22 363, FD33022363

    FD 33022 363, FD 33022363, FD330-22 363

    FD330 22 363, FD33022 363, FD33022363

    FD 33022 363, FD330-22363, FD 330-22363

    Goodyear

    2B12-425/311, 2B12 425/311, 2B12425/311

    Triangle

    6316/4363

    Airkraft115061/3B-356
    VibracousticVSP2B22R7180
    EI Ride8030190
    LelandSc2075
    Navistar1685179C1
    Hendrickson1VA1816
    Ridewell1003587180C
    SAF Holland57007180
    Watson & ChalinlAS0154 1G/01881F, AS01541G/01881F
    Peerless0550 00001

    Style 22, We Can Supply Other Models


    • Blind nuts, 1/4 NPT

    W01-358-7180, W013587180, W01 358 7180, WO1-358-7180, WO13587180, WO1 358 7180

    W01-358-7122, W013587122, W01 358 7122, WO1-358-7122, WO13587122, WO1 358 7122


    • Blind nuts, 1/4 NPT, bumper

    W01-358-7400, W01 358 7400, W01 358 7400, WO1-358-7400, WO1 358 7400, WO13587400


    • Blind nuts, 3/4 NPT

    W01-358-7184, ​W01 358 7184, ​W013587184, ​WO1-358-7184, WO1 358 7184, WO13587184


    • Blind nuts, 3/4 NPT, bumper
    W01-358-7185, W01 358 7185, W013587185, WO1-358-7185, WO1 358 7185, WO13587185
    • Countersunk steel bead rings, 15/8 bolts, nuts, washers
    W01-358-7431, W01 358 7431, W013587431, WO1-358-7431, WO1 358 7431, WO13587431
    • Rubber bellows only
    W01-358-0226, ​W01 358 0226, ​W013580226, ​WO1-358-0226, WO1 358 0226, WO13580226


    The Related Pictures of 2B6330
