    Goodyear Goodyear Single Bellow Air Spring 1B12-300 H. 160 MM Industrial Air Bag

    Ask Lasest Price
    Brand Name : AIRSUSTECH
    Model Number : 1B5330
    Certification : ISO/TS16949:2009
    Price : Negotiable
    Payment Terms : T/T, Western Union, Paypal or Others
    Supply Ability : 1000PCS/Week
    Delivery Time : 5-8 Working Days
    • Product Details
    • Company Profile

    Goodyear Goodyear Single Bellow Air Spring 1B12-300 H. 160 MM Industrial Air Bag

    Goodyear Goodyear Single Bellow Air Spring 1B12-300 H. 160 MM Industrial Air Bag

    1B5330 Specification

    • Air hole/gas fitting/ gas hole

    Air inlet: 1/4 NPTF


    • Nuts/screws

    Screw center distance: 157.5 mm

    Distance gas hole between nut: 73 mm

    Plate hole/stud qty: two on one plate

    Threaded hole type: 2×3/8-16 UNC


    • Height

    Maximum height: 160 mm

    Minimum height: 55 mm

    Stroke height: 105 mm


    • Rubber bellows

    The max diameter: 325 mm

    Material: rubber and stainless


    Cross References


    Goodyear

    1B12-300/313, 1B12 300/313, 1B12300/313


    Firestone

    W01-358-7008, W01 358 7008 W013587008, WO1-358-7008, WO13587008, WO1 358 7008


    Contitech

    FS 330-11 474, FS330-11 474, FS330-11474, FS 330 11 474, FS330 11 474, FS33011 474, FS330-11 474, FS330 11474, FS33011474


    Triangle

    6374, 4474


    Holland(Neway)

    90557226


    Firestone Style 19 has the following air springs


    Blind nuts, 1/4 NPT

    W01-358-7008, W01 358 7008, W013587008

    WO1-358-7008, WO1 358 7008, WO13587008

    Blind nuts, 1/4 NPT, bumper

    W01-358-7009, W01 358 7009, W013587009

    WO1-358-7009, WO1 358 7009, WO13587009

    Blind nuts, 3/4 NPT

    W01-358-7011, W01 358 7011, W013587011

    WO1-358-7011, WO13587011, WO13587011

    Blind nuts, 3/4 NPT, bumper

    W01-358-7012, W01 358 7012, W013587012

    WO1-358-7012, WO1 358 7012, WO13587012

    Countersunk steel bead rings, 15/8 bolts, nuts, washers

    W01-358-7023, W01 358 7023, W013587023

    WO1-358-7023, WO1 358 7023, WO13587023

    Rubber bellows only

    W01-358-0134, W01 358 0134, W013580134

    WO1-358-0134, WO1 358 0134, WO13580134


    Company Advantages
    • Universal test machine, South Korea imported
    • The United States imports MTS849 shock absorber test-bed
    • High temperature creep test machine
    • Rubber high temperature dynamic fatigue testing machine
    • Ozone aging machnie, imported from the UK
    • Vertical fatigue testing machine
    • Microcomputer control election universal testing machine
    More than 10 fully functional air spring experimental and testing equipment, rubber from the sales, to ensure that products of each process have the most stringent quality testing, so taht product quality more good safety and stability.

    The Related Pictures


    Quality Goodyear Goodyear Single Bellow Air Spring 1B12-300 H. 160 MM Industrial Air Bag for sale
