Brand Name : | AIRSUSTECH Air Springs |
Model Number : | 2B12×2T |
Certification : | ISO/TS16949:2009 |
Price : | Negotiable |
Payment Terms : | T/T, Western Union, Paypal or Others |
Supply Ability : | 1000PCS/Week |
Delivery Time : | 5-8 Working Days |
AIRSUSTECH actuators are playing a crucial role in modern machine
design as pneumatic actuators in industrial applications.
Due to their durability, ability to withstand abrasive
environments, and exceptional performance, AIRSUSTECH actuators are
becoming a popular replacement for traditional pneumatic and
hydraulic cylinders.
2B12×2T Specifications:
Air Inlet | 1/2 BSP | Minimum Height | 74 mm |
Screw Type | 4×M10 | Maximum Height | 240 mm |
Distance Air Hole Betweeen Screw | 116 mm | Static Height | 160 mm |
Screw Center Distance | 232 mm | Sroke Height | 166 mm |
Screw Bolts Height | 25 mm | Installation Diameter | 345 mm |
Top Cover Plate Diameter | 260 mm | Bellow MAX. Diameter | 330 mm |
Bottom Cover Plate Diameter | 260 mm | Operation | Gas-filled |
Cross References:
Firestone | W01-R58-4061, W01 R58 4061, W01R584061 WO1-R58-4061, WO1 R58 4061, WO1R584061 |
Contitech | FD 412-22 DS, FD 412 22 DS, FD41222DS, FD 412-22DS FD 41222DS, FD 412 22DS, FD412-22 DS, FD412 22 DS |
Dunlop Pneuride | 12''×2 |
Dunlop Springride | SP1541, SP 1541 |
Norgren | M/31122 |
Parker | 9109041 |
We Supply Other Double Convoluted Air Springs:
OEM NO. | MIN.H. | MAX. H. | MAX. Diameter | Cover Plate OD. | Screw Type |
12×2 | 74 mm | 240 mm | 330 mm | 260 mm | M10 |
10×2 | 70 mm | 240 mm | 280 mm | 210 mm | M10 |
91/4×2 | 70 mm | 240 mm | 260 mm | 197 mm | M10 |
8×2 | 72 mm | 225 mm | 230 mm | 184 mm | M10 |
6×2 | 73 mm | 170 mm | 168 mm | 153 mm | M10 |
41/2×2 | 65 mm | 145 mm | 125 mm | 110 mm | M6 |
Our Suspension Air Springs provide technical support and services for our customers. We have a team of experienced professionals to ensure that our products meet the highest standards of quality and performance. Our team is available to answer any questions or concerns you may have about our products. We also offer installation and repair services for our Suspension Air Springs. In addition, we provide a full range of spare parts and accessories to ensure that your product is always operating at its best.
The Real Pictures of 2B12×2T:
![]() |
