Brand Name : | AIRSUSTECH Air Springs |
Model Number : | 1B 4 1/2 P |
Certification : | ISO/TS16949:2009 |
Price : | Negotiable |
Payment Terms : | T/T, Western Union, Paypal or Others |
Supply Ability : | 1000PCS/Week |
Delivery Time : | 5-8 Working Days |
One common use for AIRSUSTECH Air Bags is with compressors in the transportation industry. Whether you're hauling heavy loads or transporting equipment, these air bags can help ensure a smooth ride and prevent damage to your vehicle or cargo. With their durable construction and reliable performance, they are a great choice for anyone looking to improve their transportation operations.
Specifications and Technical Parameters: 1B 4 1/2 P
Specifications:
Air Hole | G 3/8 |
Nuts Type | 3×M6 |
Distance Air Hole Betweeen Nuts | 46.5 MM |
Top Cover Plate Diameter | 110 MM |
Bottom Cover Plate Diameter | 110 MM |
Bellow MAX. Diameter | 125 MM |
Installation Diameter | 140 MM |
Minimum Height | 50 MM |
Maximum Height | 90 MM |
Pressure Ability | 3-8 Bar |
Mini Pressure | 0 Bar |
Technical Parameters:
Pressure [bar] | 3 | 4 | 5 | 6 | 7 | 8 | Vol. V [I] |
Force (Load) [kN] | 1.5 | 2.1 | 2.7 | 3.2 | 3.8 | 4.4 | 0.27 |
Spring Rate [N/mm] | 112 | 141 | 169 | 198 | 226 | 253 | |
Natural frequency [Hz] | 4.2 | 4.1 | 4.0 | 3.9 | 3.8 | 3.8 |
Pressure | [bar] | 3 | 4 | 5 | 6 | 7 | 8 | Vol. V [I] |
Height H [mm] | 80 | 1.02 | 1.44 | 1.87 | 2.3 | 2.74 | 3.2 | 0.32 |
70 | 1.58 | 2.15 | 2.7 | 3.3 | 3.88 | 4.5 | 0.27 | |
60 | 2.17 | 2.89 | 3.62 | 4.34 | 5.08 | 5.85 | 0.22 |
Cross References:
Firestone | W01-R58-4050, W01R584050, W01 R58 4050 WO1-R58-4050, WO1R584050, WO1R584050 |
Contitech | FS 44-5 DI, FS 44 5 DI, FS445DI, FS44-5 DI FS44-5DI, FS 445 DI, FS 44-5DI, FS 445DI |
NORGREN | PM/31041 |
PARKER | 9109400 |
DUNLOP PNEURIDE | 4 1/2" x 1 |
DUNLOP SPRINGRIDE | SP2334, SP 2334 |
Support and Services:
The Real Pictures of 1B4 1/2P:
![]() |
