Product Description:
One of the standout features of the Torpress air spring is its
outstanding durability cycle. With over 10 cycles, this air spring
is built to last and withstand the most demanding driving
conditions. Whether you are driving over rough terrain or carrying
heavy loads, the air spring will give you the support and stability
you need.
With an operating pressure of ≤ Mpa, the Torpress air spring is
suitable for a wide range of vehicles. Whether you own a small car
or a large truck, this air spring will provide optimal performance
and reliability.
If you are looking for a high-quality Pirelli gas-filled air spring
for your vehicle, the Torpress air spring is an excellent choice.
With its superior durability, long-lasting performance and reliable
support, this air spring is the perfect addition to any vehicle.
Features:
- Product Name: Torpress Air Spring
|
- Replace: Pirelli Model 20
|
|
|
- Connecting Bolts or Holes: 8PCS M8X1
|
| Pirelli Air Lift Suspension, Pirelli Air Lift Suspension, Pirelli
Inflatable Air Springs |
Technical Parameters:
1. Nut / Blind Nut
The number of Top Cover Plate Screws (Nuts) is 8, with a thread
specification of M8X1. The tooth count is also 8. The Screw center
distance of the Top Cover Plate is 160.3 mm. The number of Bottom
Cover Plate Screws (Nuts) is also 8, with a thread specification of
M8X1. The Screw center distance of the Bottom Cover Plate is 160.3
mm
2. Gas Hole / Air inlet / Air Fitting
The product does not contain Gas Hole and Air inlet
3. Cover Plate
The product's Top and Bottom Cover Plate Diameter (Width) is 179 mm
4. Rubber Bellows
The product has a Rubber Bellows with a maximum diameter of 255 mm
and a natural diameter of 224 mm. It has a working stroke ranging
from MAX 265 mm to MIN 80 mm. The compressed height is 80 mm or
3.12 inches, while the design height is 178 mm-203 mm or 7-8
inches. The product has 20 bellows #.
5. Bumper block / Buffer block
The product does not contain Bumper Block.
6. Girdle Hoop / Girdle Ring
The product has One Piece of Girdle Hoop.
Applications:
Air spring products are essential parts for industrial machinery,
providing reliable and long-lasting performance. Its connection
type F2 is compatible with a wide range of machines and equipment.
The part weight is 5.0 Kg, which is lightweight and easy to
install.
Air spring products are suitable for a variety of applications and
scenarios. It is commonly used in industrial machinery such as
heavy trucks, forklifts, and construction equipment.
Packing and Shipping:
Product Packaging for Air Spring:
The Air Spring is packaged securely in a sturdy cardboard box with
foam inserts to prevent any damage during shipping. The box is
labeled with the product name, model number, and quantity. Inside
the box, you will find the Air Spring, along with any additional
components or accessories.
Shipping Information for Air Spring:
Orders are typically processed and shipped within 1-3 business
days. Once your order is shipped, you will receive a tracking
number via email. Please allow 5-7 business days for delivery.
