Brand Name : | AIRSUSTECH |
Model Number : | 1B8×4 |
Certification : | ISO/TS16949:2009 |
Price : | Negotiable |
Payment Terms : | T/T,Western Union,Paypal or Others,L/C,D/A,D/P,MoneyGram |
Supply Ability : | 1000pcs/week |
Delivery Time : | 3-8 Working Days |
AIRSUSTECH 1B8×4 Rubber Air Spring Cross Contitech FS 120-10 Air Spring Assembly
Product Dimensions
Dimensions - Min. Compressed Height: 50 MM |
Dimensions - Max. Extended Height: 140MM |
Dimensions - Maximum Diameter: 230 MM |
Dimensions - Cover Plate Diameter: 135 MM |
Dimensions - Center to Center Distance: 70 MM |
Screw Type: 2×3/8-16UNC |
Air Hole Standard: 1/4NPTF |
Manufacturer Part Numbers
Manufacturer: Contitech
Reference: FS 120-10, FS 12010, FS 120 10
Manufacturer: Firestone
Reference: W01-358-7564, W013587564, W01 358 7564
Manufacturer: Goodyear
Reference: 1B8-550, 1B8550, 1B8 550
Manufacturer: Firestone
Reference: W01-M58-6166, W01M586166, W01 M58 6166
Manufacturer: Bosch
Reference: 1923081000
Manufacturer: Enidine
Reference: YI1B8850, YI 1B8 850, YI-1B8-850
Manufacturer: Goodyear
Reference: 1B8-850, 1B8850, 1B8 850
Reference: 579-91-3-530, 579913530, 579 91 3 530
Air Spring Should Pay Attention To In The Application
1. It is forbidden to use the air spring beyond the recommended
safe extension height.
2. In order to prolong the service life of the air spring, do not
use the air spring below the minimum compression height.
3. Do not use the air spring under the pressure exceeding 0.7Mpa.
4. Do not use the air spring in a twisted state.
AIRSUSTECH Rubber Air Spring Cross Other Pneumatic Air Bags
AIRSUSTECH Number | Cross OEM References |
1B130070 | Contitech FS 50-5 |
1B6910 | Contitech FS 200-10 |
1B1209 | Firestone W01-M58-6165 |
1B5330 | Firestone W01-358-7008 |
1B8×4 | Firestone W01-358-7564 |
1B7070 | Contitech FS 70-7 |
