    G1/8 Port Size Rubber Air Spring Contitech FS 40-6 Air Suspension OEM Supplier

    Ask Lasest Price
    Brand Name : AIRSUSTECH
    Model Number : 1B4060
    Certification : ISO/TS16949:2009
    Price : Negotiable
    Payment Terms : T/T, Western Union, Paypal or Others
    Supply Ability : 1000PCS/Week
    Delivery Time : 5-8 Working Days
    • Product Details
    • Company Profile

    G1/8 Port Size Rubber Air Spring Contitech FS 40-6 Air Suspension OEM Supplier

    G1/8 Port Size Rubber Air Spring Contitech FS 40-6 Air Suspension OEM Supplier


    1B4060 Specifications


    Dimensions - Height[Min]: 50 mm

    Dimensions - Height[Max]: 110 mm

    Dimensions - Cover Plate Diameter: 90 mm

    Dimensions - Maximum Diameter: 145 mm

    Dimensions - Center to Center Diameter: 20 mm

    Pneumatic Connection: G1/8

    Screw Type: M8×1.25


    1B4060 Technical Data Sheet


    Vibration isolation - dynamic characteristics values

    Pressure P [bar]345678Vol. V[l]
    Force (Load) [kN]1.72.32.83.43.84.40.5
    Spring Rate [N/cm]7609901220148016101820
    Natural Frequency [Hz]3.53.33.33.33.23.2

    Pneumatic application - static characteristic values

    Pressure p[bar]245678Vol.[l]
    Height H [mm]1001.21.62.02.53.03.40.6
    901.72.22.83.43.94.40.5
    802.12.83.54.24.95.30.5
    702.33.23.94.75.46.20.4
    602.63.54.35.26.16.90.3

    Corresponding International Models


    Contitech OEM Manufacturer FS 40-6

    Contitech OEM Manufacturer FS 406

    Contitech OEM Manufacturer FS 40 6
    Phoenix OEM Manufacturer SP 1B 04

    Phoenix OEM Manufacturer SP 1B04

    Phoenix OEM Manufacturer SP1B04
    Weforma OEM Manufacturer WBE 100-E1

    Weforma OEM Manufacturer WBE 100E1

    Weforma OEM Manufacturer WBE100E1


    The Applications of AIRSUSTECH Rubber Air Suspensions

    1Dynamic stability protection of cargo
    The air spring forms a flexible buffer layer by filling the gaps in the container, effectively absorbing the vibration and impact of the ship during navigation and preventing the displacement of cargo. Its adaptive pressure adjustment function can cope with different types of cargo, especially suitable for the transportation protection of fragile or precision equipment.
    2Liquid cargo transportation stability solution
    For highly fluid liquids such as chemicals and oils, the air spring constructs a three-dimensional constraint structure to significantly reduce the liquid sloshing caused by the ship's turbulence. By evenly dispersing the fluid kinetic energy, the vehicle balance is maintained to avoid safety hazards caused by liquid inertia.
    3Container space optimization system
    The modular air spring supports customized fixation of special-shaped cargo and adapts to different loading forms through intelligent inflation and deflation adjustment. This solution can not only improve the utilization rate of container space, but also reduce the use of traditional filling materials and reduce the overall transportation cost.


    The Related Photos of 1B4060
