    Rolling Lobe Air Spring 1R9-065 by Goodyear Air Actuator for Hendrickson Trailer

    Ask Lasest Price
    Brand Name : AIRSUSTECH
    Model Number : 1T2199
    Certification : ISO/TS16949:2009
    Price : Negotiable
    Payment Terms : T/T, Western Union, Paypal or Others
    Supply Ability : 1000PCS/Week
    Delivery Time : 5-8 Working Days
    • Product Details
    • Company Profile

    Rolling Lobe Air Spring 1R9-065 by Goodyear Air Actuator for Hendrickson Trailer

    Rolling Lobe Air Spring 1R9-065 by Goodyear Air Actuator for Hendrickson Trailer


    Product Fetaures


    Maximum Height: 290 mm

    Compressed Height: 82 mm

    Top Plate Diameter: 160 mm

    Piston Width: 179 mm

    Air Bellows Diameter: 185 mm

    Center to Center Distance Diameter: 86 mm

    Screw Type: 3/4-16 UNF

    Pneumatic Connection: 1/4NPTF


    Alternative Models of Air Springs


    Goodyear Part Number: 1R9-065

    Goodyear Part Number: 1R 9-065

    Goodyear Part Number: 1R 9065

    Goodyear Part Number: 1R9065

    Goodyear Part Number: 1R9 065

    Goodyear Bellows Number: 566-18-3-003

    Goodyear Bellows Number: 566183003

    Goodyear Bellows Number: 566 18 3 003

    Firestone: W01-358-2119

    Firestone: W013582119

    Firestone: W01 358 2119

    Firestone Bellows Number: 1T14C-1

    UPC: 767555002124
    Rowe Truck Number: ASC1400HL
    Hendrickson Trailer Number: S-2394 / B2394
    Granning Number: 5122
    ContiTech Bellows Number: 6 6.5B-11
    ContiTech Number: 6 6.5B-11 S 027, 68108


    The Advantages of AIRSUSTECH Air Suspensions/Air Actuators


    1. Excellent shock absorption
    2. Stable shock absorption
    3. Precise height control
    4. Wide range of sizes
    5. Extend equipment life
    6. Effectively reduce noise
    7. Air spring shock absorbers are widely used

    We Have Other Air Bag Replacements to Goodyear Air Springs


    TRUCK & TRAILER AIR SPRINGS
    1R11-0281R11-2191R11-2201R11-2211R11-242
    1R11-2681R112-0921R12-3751R12-4011R12-403
    1R12-4191R12-4321R12-4841R12-5341R12-541
    1R12-5471R12-5521R12-5531R12-5551R12-602
    1R12-6031R12-6421R12-6641R12-10931R13-039
    1R13-1181R13-1191R13-1551R13-2391R14-117
    1R14-1271R14-1591R14-1601R14-1711R14-172
    1R12-215
    TRUCK CABIN AIR SPRINGS
    1S4-0071S4-0081S4-0671S4-2341S5-005
    1S5-0381S5-0571S5-1521S5-1541S5-157
    1S5-1641S5-1751S5-1761S5-1861S6-023
    1S6-0552B9-2012B9-4952B12-406

    The Detailed Pictures





    Company Profile

    Guangzhou Guomate Air Spring Co., Ltd. is located in Guangzhou, China's first open port, just a fifteen-minute drive from Guangzhou Baiyun International Airport. The company boasts a modern building with an area of ​​approximately 20,000 square meters and state-of-the-art production facilities for rubber air springs. It is currently the largest air spring production base in China. The company's products are primarily used in commercial vehicles, rail vehicles, and industrial machinery and equipment. The main products are: rubber air springs, bus airbags, truck airbags, air springs for the paper machine industry, airbags for large washing machines, and rubber air springs for automobiles. We currently offer hundreds of models and designs and can also design and produce according to customer requirements or existing product specifications. New and existing customers are welcome to contact us for a consultation. Our company utilizes state-of-the-art domestic air spring processing facilities and integrates foreign air spring production technologies. Thanks to our unique production process, we produce according to international standards and thus create world-class products.
