    Firstone Pneumatic Actuator W01-358-7823 Single Rubber Bellow with Aluminum Plate

    Ask Lasest Price
    Brand Name : AIRSUSTECH
    Model Number : 3H7823
    Certification : ISO/TS16949:2009
    Price : Negotiable
    Payment Terms : T/T, Western Union, Paypal or Others
    Supply Ability : 1000PCS/Week
    Delivery Time : 5-8 Working Days
    • Product Details
    • Company Profile

    Firstone Pneumatic Actuator W01-358-7823 Single Rubber Bellow with Aluminum Plate

    Firstone Pneumatic Actuator W01-358-7823 Single Rubber Bellow with Aluminum Plate


    Product Detailed Datas


    Cover Plate
    Top Cover Plate Diameter: 17.75 inches
    Screw Center Distance of Top Cover Plate: 16.50 inches
    Bottom Cover Plate Diameter: 17.75 inches
    Screw Center Distance of Bottom Cover Plate: 16.50 inches


    Nut/Blind Nuts
    Top Cover Plate Screw(Nut) Tooth: 24 (3/8-24) bolts
    Bottom Cover Plate Screw(Nut) Tooth: 24 (3/8-24) bolts


    Rubber Bellow
    Rubber Bellow Max. Diameter: 20.50 inches
    Minimum Height: 4.60 inches
    Maximum Height: 18 inches


    Product Technical Data Sheets


    Dynamic Characteristics at 13.0 in. Design Height
    Volume @ 100 PSIG = 3,073 in3Natrual Frequency
    Gage Pressure (PSIG)Load (Ibs.)Spring Rate (Ibs./in.)CPMHZ
    408,0101,744881.46
    6012,0302,104781.31
    8016,2702,784781.30
    10020,5803,624791.31

    Force Table
    Assembly Height (in.)Volume @ 100 PSIG (in3)

    @ 20

    PSIG

    @ 40

    PSIG

    @ 60

    PSIG

    @ 80

    PSIG

    @ 100

    PSIG

    15.03,4703,2206,64010,28013,96017,740
    13.03,0733,9608,01012,03016,27020,580
    11.02,6324,3308,91013,42018,03022,770
    9.02,1504,7409,61014,45019,41024,420
    7.01,6395,03010,12015,41020,77026,200
    5.01,0935,61011,14016,59022,38028,170

    OEM Cross Reference

    DescriptionAssembly Order No.

    Style 323

    Two Ply Bellows

    Ribbed neck aluminum bead rings (equal spacing), 17/8 bolts, nuts, washers

    W01-358-7823, W013587823, W01 358 7823

    WO1-358-7823, WO13587823, WO1 358 7823

    Rolled plate assembly, 1/2 blind nuts, 3/4 NPTW01-358-7274, W013587274, W01 358 7274

    WO1-358-7274, WO13587274, WO1 358 7274

    Rubber bellows onlyW01-358-7921, W013587921, W01 358 7921

    WO1-358-7921, WO13587921, WO1 358 7921

    Style 324

    High Strength Bellows

    Ribbed neck aluminum bead rings (equal spacing), 17/8 bolts, nuts, washersW01-358-7829, W013587829, W01 358 7829

    WO1-358-7829, WO13587829, WO1 358 7829

    Rubber bellows onlyW01-358-0324, W013580324, W01 358 0324

    WO1-358-0324, WO13580324, WO1 358 0324


    AIRSUSTECH Air Bags Product Technical Support


    1. Provides additional support for your vehicle's suspension system
    2. Helps to reduce vehicle sagging, sway, and bottoming out
    3. Easy to install and inflate/deflate as needed
    4. Constructed with high-quality materials for durability and longevity
    5. Available in a variety of sizes to fit most vehicles
    6. AIRSUSTECH Air Bags Product Services:
    7. Professional installation available through authorized dealers
    8. Warranty included with product purchase
    9. Online resources available for product information and troubleshooting
    10. Customer service available for any questions or concerns


    The Related Pictures



    FAQ


    Q: Can you print my logo on inner box and outer box?
    A: Yes. We can do it, but it has MOQ.


    Q: What is your advantage?
    A: (1) High quality - Natural rubber.
    (2) Fast delivery - Stock sales.
    (3) Best service - 24 hours online.


    Q: What's your advantage?
    A: (1) Resonable price, good service
    (2) Reliable quality, long working life
    (3) Quick and safe modes of payment
    (4) Ships items timely and quickly
    (5) Our products are exported to most countries in the world


    Q: How do you guarantee quality?
    A: We have testing on aging, hardness, bending, tension, viscosity, rheology, water inspection, bursting, fatigue, etc.
