Air Suspension Weforma WBE 200-E1 G 1/4 Air Connection for Truck Air Spring

Guangzhou Guomat Air Spring Co., Ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now
    Buy cheap Air Suspension Weforma WBE 200-E1 G 1/4 Air Connection for Truck Air Spring from wholesalers

    Buy cheap Air Suspension Weforma WBE 200-E1 G 1/4 Air Connection for Truck Air Spring from wholesalers
    • Buy cheap Air Suspension Weforma WBE 200-E1 G 1/4 Air Connection for Truck Air Spring from wholesalers
    • Buy cheap Air Suspension Weforma WBE 200-E1 G 1/4 Air Connection for Truck Air Spring from wholesalers
    • Buy cheap Air Suspension Weforma WBE 200-E1 G 1/4 Air Connection for Truck Air Spring from wholesalers
    • Buy cheap Air Suspension Weforma WBE 200-E1 G 1/4 Air Connection for Truck Air Spring from wholesalers

    Air Suspension Weforma WBE 200-E1 G 1/4 Air Connection for Truck Air Spring

    Ask Lasest Price
    Brand Name : AIRSUSTECH
    Model Number : 1B7070
    Certification : ISO/TS16949:2009
    Price : Negotiable
    Payment Terms : T/T, Western Union, Paypal or Others
    Supply Ability : 1000PCS/Week
    Delivery Time : 5-8 Working Days
    • Product Details
    • Company Profile

    Air Suspension Weforma WBE 200-E1 G 1/4 Air Connection for Truck Air Spring

    Air Suspension Weforma WBE 200-E1 G 1/4 Air Connection for Truck Air Spring


    Product Introduction


    Suspension Air Springs are high-performance air shocks built for durability, strength, and excellent load capacity across various automotive applications. Constructed with premium rubber and steel, they perform reliably in temperatures from -40℃ to +70℃. These air springs enhance shock absorption and stability, ensuring a smoother, safer ride for vehicles of all types. Easy to install and low-maintenance, they are an ideal solution for any vehicle.


    Refer Number


    Weforma

    WBE 200-E1 / WBE200-E1 / WBE200E1

    Contitech

    FS 70-7 / FS70-7 / FS707

    Phoenix

    SP 1B 05 / SP1B05 / SP1B 05

    Bosch

    8224 19002 / 822419002

    Festo

    EB-165-65 / EB 165 65 / EB16565

    Firestone

    W01-M58-6155 / W01 M58 6155 / W01M586155


    Product Features


    Bottom Plate Alignment: Parallel
    Bottom Plate Center To Center Diameter: 44.5 mm
    Bottom Plate Diameter: 105 mm
    Bottom Plate Hole Quantity: 2
    Bottom Plate Type: Steel


    Top Plate Alignment: Parallel
    Top Plate Center To Center Diameter: 44.5 mm
    Top Plate Diameter: 105 mm
    Top Plate Hole Quantity: 3
    Top Plate Type: Steel


    Bellow Maximum Diameter: 165 mm
    Expanded Height: 115 mm
    Compressed Height: 50 mm
    Spring Type: Single Convoluted
    Nut/Blind Nuts Type: 4×M8×1.25


    Air Connection: G1/4
    Type: Gas-filled


    AIRSUSTECH Air Spring Advantage


    Low installation height
    In comparison to conventional pneumatic cylinders, ContiTech air actuators contain no piston rod, making it possible to reduce
    the design height considerably.This allows compact constructions to be made.


    Angular movement
    Depending on the type, AIRSUSTECH
    air actuators can be used for tilt angles up to 30°. This enables the designer to simplify the articulated construction.


    Low purchase price
    The purchasing costs are considerably less than for conventional pneumatic cylinders.And thanks to the long service life and freedom from maintenance,running costs are reduced as well.


    1B7070 Real Images



    Quality Air Suspension Weforma WBE 200-E1 G 1/4 Air Connection for Truck Air Spring for sale
