    W01-358-7919 Firestone Industrial Air Springs 3B7919 Big Dia. 27.9 Inch MAX O.D. AT 100 PSIG

    Ask Lasest Price
    Brand Name : AIRSUSTECH
    Model Number : 3B7919
    Certification : ISO/TS16949:2009
    Payment Terms : T/T, Western Union,Paypal or Others
    Supply Ability : 1000pcs/week
    Delivery Time : 3-8 Working Days
    • Product Details
    • Company Profile

    W01-358-7919 Firestone Industrial Air Springs 3B7919 Big Dia. 27.9 Inch MAX O.D. AT 100 PSIG

    W01-358-7919 Firestone Industrial Air Springs 3B7919 Big DIA. 27.9 Inch MAX O.D. AT 100 PSIG


    Detailed Product Description:


    Material:Aluminum Alloy And RubberGUOMAT:

    W01-358-7919

    Warranty:12 MonthsNet Weight:10.5 KG
    Other Name:Industry Air Spring IsolatorPressure Ability:0.2-0.8 M Pa
    Gross Weight:12.5 KGFlange Ring:With Or Without
    Connection Method:Flange ConnectionFlange Ring Size:638 Mm
    BOLT CIRCLE DIA:596 Mm

    3B7919 Industrial Triple Convoluted Air Spring Specifications


    Description Assembly

    Description
    Assembly Order No.
    Style 321
    Ribbed neck aluminum bead rings (equal spacing), 45 mm bolts, nuts, washers
    W01-M58-6984
    Two Ply Bellows
    Rubber bellows only
    W01-358-7919

    Manufacturer Part NumberShort Description W01-M58-7919
    , W01M587919
    , WO1-M58-7919
    WO1M587919
    Bead ring Type4
    Maximum Diameter @ 7 Bar (mm)709Dim# C (Bolt Circle Diameter mm)597
    Maximum Height (mm)114# of Bolts (each ring)32
    Maximum Stroke (mm)361Design Height (mm)381
    Minimum Usable Height (mm)4753 Bar (kN)78.5
    25 mm (kN)174.65 Bar (kN)132.9
    50% of Max Stroke (kN)1507 Bar (kN)187.9
    Maximum Stroke (kN)106.5Natural Frequency (@5 Bar)(fn(Hz)1.2
    Applicable Technigram?1137 Hz97
    Material2-Ply, High Strength Cord13 Hz99.3
    25 Hz99.8

    ORDER NUMBER STYLE NUMBER SEE PAGEORDER NUMBER STYLE NUMBER SEE PAGE
    W01-M58-6353 26 58
    W01-M58-6369 113-1 48W01-M58-6983 320 77
    W01-M58-6371 113-1 48W01-M58-6984 319 78
    W01-M58-6372 19 45W01-M58-6985 203 67
    W01-M58-6373 19 45W01-M58-6986 203 67
    W01-M58-6374 115 44W01-M58-6987 29 68
    W01-M58-6375 115 44W01-M58-6988 26 58
    W01-M58-6376 115 44W01-M58-6990 20 59
    W01-M58-6377 21-2 64W01-358-7019 333 74
    W01-M58-6378 21-2 64W01-M58-7524 22 61
    W01-M58-6379 21-2 64W01-M58-7525 21 63
    W01-M58-6381 22 61W01-M58-7526 313 73
    W01-M58-6382 22 61W01-M58-7530 312 75
    W01-M58-6383 22-1.5 62W01-M58-7531 28 66
    W01-M58-6384 22-1.5 62W01-M58-7532 29 68
    W01-M58-6387 26 58W01-M58-7533 319 78

    Technical performance parameter list of air spring
    Bearing
    load
    Power
    (kg)
    Inflation pressure0.2MPa0.3MPa0.4MPa0.5MPa0.6MPa0.7MPa0.8MPa0.7MPa
    Volume(dm³)
    Installation height
    122(mm)704910605141181771921471250442871935.53
    206(mm)64739614129581620519676230172640562.50
    290(mm)58438783118031478917930210822414885.26
    376(mm)525979931082013620164831933922216105.14
    416(mm)48207333984912370150221768920366113.46
    436(mm)46187086947412021146021716919821116.67
    458(mm)43866600890311318137881635418929122.04
    Stiffness and frequency at design heightVertical stiffness(Kg/cm)480653768934110712451393
    Stiffness and frequency at design heightHz1.511.431.331.311.301.271.25
    Stiffness and frequency at design heightcpm91868079787675


    W01-358-7919 Firestone Industrial Air Springs 3B7919 Big Dia. 27.9 Inch MAX O.D. AT 100 PSIGW01-358-7919 Firestone Industrial Air Springs 3B7919 Big Dia. 27.9 Inch MAX O.D. AT 100 PSIG
