    Norgren M/31122 Industrial Air Springs Bellow Single Convolution 12" Diameter With Stroke 225mm

    Ask Lasest Price
    Brand Name : AIRSUSTECH
    Model Number : 2B12X2
    Certification : ISO/TS16949:2009
    Payment Terms : T/T, Western Union,Paypal or Others
    Supply Ability : 1000pcs/week
    Delivery Time : 3-8 Working Days
    • Product Details
    • Company Profile

    Norgren M/31122 Industrial Air Springs Bellow Single Convolution 12" Diameter With Stroke 225mm

    Norgren M/31122 Industrial Air Springs Bellow Single Convolution 12" diameter With Stroke 225mm

    AIRSUSTECH 2B12X2 Cross other OEM:


    AIRSUSTECH NO. 2B12X2

    Norgren NO. M/31122

    Norgren NO. M 31122

    Norgren NO. M31122

    Weweler USN 510011KD

    Contitech FD 412-18 1/2 M10

    Order No 60040070 ST 20301.F Air Spring
    Gigant 881202

    Firestone W01 R58 4061
    Granning 15813

    Goodyear 2B12-2452 Ø260
    Goodyear 578-92-3-2452 Rp 1/2"
    Airtech 2B-300 / 113300

    Weight (Kg): 6,42 QIP: 45

    Order No 60040071 ST 20301-01.F Air Spring

    BPW HB10350

    Contitech FD 412-18 P01
    Fruehauf UJB 0985

    Firestone 12 x 2 NB
    SAE-SMB M063796

    Firestone W01-R58-4073 Ø260
    Granning 15814 Goodyear 2B12-2457
    Goodyear 578-92-3-2452 M16x1.5
    Airtech 2B -300 / 113301 4xM10x1.5


    Specifications and Detail Technical Parameters:Style12" x2


    Nut / Blind Nut

    Top Cover Plate Screw (Nut) Tooth : 4pcs X M10


    Bottom Cover Plate Screw (Nut) Tooth : 4pcs X M10


    Gas Hole / Air inlet / Air Fitting

    Gas Hole / Air inlet : G1/2


    Cover Plate

    Top Cover Plate Diameter (Width): 210 mm


    Bottom Cover Plate Diameter (Width): 210 mm


    Material top and bottom plate:Steel


    Rubber Bellows


    Stroke of Rubber Bellows:75mm-300m


    Bumper block / Buffer block

    Without Bumper Block

    Girdle Hoop / Girdle Ring

    With Girdle Hoop :One Pieces of Girdle Hoop


    Rubber material Standard up to 70°C natural rubber
