    W01-358-7460 Firestone Air Spring Style 115 For Hot Foil Stamping Machine

    Ask Lasest Price
    Brand Name : AIRSUSTECH
    Model Number : 1B7460
    Certification : ISO/TS16949, ISO9001
    Payment Terms : T/T, Western Union,Paypal or Others
    Supply Ability : 1000pcs/week
    Delivery Time : 3-8 Working Days
    • Product Details
    • Company Profile

    W01-358-7460 Firestone Air Spring Style 115 For Hot Foil Stamping Machine

    W01-358-7460 Firestone Air Spring Style 115 For Hot Foil Stamping Machine

    W01-358-7460 Firestone OEM Original Equipment Manufacturer:

    AIRSUSTECH Part number:1B7460

    Norgren Part number:PM/31091(81/4x1)
    Norgren Part number:PM/31091

    Norgren Part number:81/4x1
    Contitech Part number: FS 200-10 1/4

    Contitech Part number: FS200-10

    Contitech Part number: FS 200-10

    Contitech Part number: FS200-10 1/4
    Phoenix Part number:SP 1B 12

    Phoenix Part number:SP1B12
    Dunlop(FR) Part number: 9’’1/4x1 S09101

    Dunlop(FR) Part number: 9’’1/4x1

    Dunlop(FR) Part number: S09101
    Bosch Part number: 822419004
    FestoPart number :EB-250-85

    Firestone Part number:W01-358-7460

    Firestone Part number:W01 358 7460

    Firestone Part number:W013587460

    Firestone Style 115

    Rubber bellows only :W01-358-0118

    Rubber bellows only :W01 358 0118

    Rubber bellows only :W013580118

    Goodyear Part number:1B9-215

    Goodyear Part number:1B9215

    Goodyear Part number:1B9 215

    Goodyear bellows number: 578912215

    Goodyear bellows number:578-91-2-215

    Goodyear bellows number:578 91 3 201
    Goodyear bellows number:578-91-3-201
    Goodyear bellows number:578913201

    ENIDINE Part number:YI-1B9-215

    ENIDINE Part number:YI1B9215

    Size of W01-358-7460 Firestone:

    Nut/blind nut

    Top plate screw (nut) teeth: 2 x 3/8-16 BLIND NUTS (5/8 DEEP)

    The screw center distance of the top cover plate: 89 mm

    Screw (nut) teeth of the bottom cover plate: 2 x 3/8-16 BLIND NUTS (5/8 DEEP)

    Screw center distance of bottom cover plate: 89 mm



    Air hole/air inlet/air fitting

    Air hole/air inlet: 1/4NPT

    Center distance between nut and air inlet: 44.5 mm



    Cover plate

    Top plate diameter (width): 160 mm

    Diameter of bottom cover (width): 160 mm



    Rubber bellows

    Rubber bellows diameter: 222 mm

    Compressed height: 100 mm / 4.1 inches

    Maximum height: 160 mm

    Working stroke: 60 mm

    Bumper block / Buffer block

    Without Bumper Block

    Girdle Hoop / Girdle Ring

    With Girdle Hoop :No of Girdle Hoop

    SPRING FEATURES

    LOAD RANGE(ISOLATOR)........

    .640-3900|b

    DESIGN HE I GHT RANGE( ISOLATOR)...4.5-5.0 in

    USEABLE STROKE w/o BUMPER (ACTUATOR)..3.0 in

    USEABLE STROKE WITH BUMPER(ACTUATOR).2.0 in

    ASSEMBLY WE I GHT

    FORCE TO COMPRESS AT 0 PS IG(APPROX)..20Ib

    NOM I NAL FREE STAND ING HT. AT 0 PSIG...5.7in


    W01-358-7460 Firestone Air Spring Style 115 For Hot Foil Stamping MachineW01-358-7460 Firestone Air Spring Style 115 For Hot Foil Stamping Machine


    Goodyear Air Spring OE NO. Goodyear Air Spring OE Bellows NO. Goodyear order NO. Bumper or not Goodyear Air Spring OE NO.
    RETAINER RING 57820915700000 20094258 Y RETAINER RING
    2BG-8034 AIR SPRING FLEX MEMBER 57823803400004 20642557 Y 2BG-8034 AIR SPRING FLEX MEMBER
    2BG-8077FORD OTOSAN AIR SPRING 57823807720004 20715680 Y 2BG-8077FORD OTOSAN AIR SPRING
    2BG-8126 AIR SPRING FLEXMEMBER JOST 57823812610004 20692287 N 2BG-8126 AIR SPRING FLEXMEMBER JOST
    2B9-8325 AIR SPRING FLEX MEMBER 57823832500004 20635338 Y 2B9-8325 AIR SPRING FLEX MEMBER
    1B9-201 57891220100000 20054257 N 1B9-201
    1B9-201 57891220100004 20116161 Y 1B9-201
    ENIDINE YI-1B9-201 57891220100019 20094261 N ENIDINE YI-1B9-201
    1B9-202 57891220200000 20094262 Y 1B9-202
    1B9-202 57891220200004 20116162 N 1B9-202
    ENIDINE YI-1B9-202 57891220200019 20094263 Y ENIDINE YI-1B9-202
    1B9-204 57891220400000 20094264 Y 1B9-204
    1B9-204 57891220400004 20116163 Y 1B9-204
    ENIDINE YI-1B9-204 57891220400019 20094266 N ENIDINE YI-1B9-204
    1B9-205 57891220500000 20094267 Y 1B9-205
    1B9-205 57891220500004 20116164 Y 1B9-205
    ENIDINE YI-1B9-205 57891220500019 20094268 Y ENIDINE YI-1B9-205
    1B9-207 57891220700000 20094269 N 1B9-207
    1B9-207 57891220700004 20116165 Y 1B9-207
    ENIDINE YI-1B9-207 57891220700019 20094270 N ENIDINE YI-1B9-207
    1B9-208 57891220800000 20094271 Y 1B9-208
    1B9-208 57891220800004 20116166 Y 1B9-208
    ENIDINE YI-1B9-208 57891220800019 20094272 N ENIDINE YI-1B9-208
    1B9-215 57891221500000 20094277 Y 1B9-215
    ENIDINE YI-1B9-215 57891221500019 20094278 Y ENIDINE YI-1B9-215
    1B9-216 57891221600000 20175039 Y 1B9-216
    1B9-216 57891221600004 20175183 Y 1B9-216
    P 1B9-202 57891221700095 20805668 N P 1B9-202
    C 1B9-202 57891221800094 20810946 Y C 1B9-202
    C 1B9-207 57891221900094 20811429 Y C 1B9-207
    3B12-335 Bellows Air Spring 3B12-335 20141254 N 3B12-335 Bellows Air Spring
    3B12-336 HENDRICKSON HEBRON 004645 57893233600000 20141257 Y 3B12-336 HENDRICKSON HEBRON 004645
    3B12-336 HENDRICKSON HEBRON 004645 57893233600004 20141258 Y 3B12-336 HENDRICKSON HEBRON 004645
    3B12-337 57893233700000 20156098 Y 3B12-337
    3B12-337 Bellows Air Spring 3B12-337 20156099 N 3B12-337 Bellows Air Spring
    3B12-338 57893233800000 20156259 Y 3B12-338
