    W01-R58-4081 Heavy Duty Air Bags Dunlop Air Ride Springs 31043

    Ask Lasest Price
    Brand Name : AIRSUSTECH
    Model Number : 2 3/4 X 3
    Certification : ISO/TS16949:2009
    Payment Terms : T/T, Western Union,Paypal or Others
    Supply Ability : 1000pcs/week
    Delivery Time : 3-8 Working Days
    • Product Details
    • Company Profile

    W01-R58-4081 Heavy Duty Air Bags Dunlop Air Ride Springs 31043

    SP 2910 Dunlop Air Spring 2 3/4 X 3 Refer to Firestone Air Bags W01-R58-4081


    AIRSUSTECH1B4 1/2 Cross OEM:


    AIRSUSTECH:2 3/4 X 3

    Firestone:W01-R58-4081

    Firestone:W01 R58 4081

    Firestone:W01R584081


    Comparable: W01R584081 W01-R58-4081 WO1R584081, WO1-R58-4081


    The Specification AIRSUSTECH 2 3/4 X 3:


    bellows type industrial air spring,

    single spiral,

    effective area 44cm,

    maximum stroke 5cm,

    movable connecting part,

    female mounting thread, G3/8 BSPP,

    neoprene (chloroprene Ene)
    Manufacturer: Mainland


    Compressed height
    1.97 inches
    Maximum expansion height
    143 mm
    The maximum diameter
    4.92 inches
    Maximum inflation pressure
    120 psi
    Maximum stroke
    63 mm
    Inlet type
    Metric
    Air inlet
    3/8"
    series
    d
    lowest temperature
    -22°F
    Maximum temperature
    194°F
    Bellows type
    Single convolution
    weight
    1 pound


    Other kinds of the Firestone W01-R58 air spring:


    W01-R58-4023 140 W01-R58-4085 133 W01-R58-4052 131 W01-R58-4076 131 W01-R58-4053 132 W01-R58-4092 135 W01-R58-4086 136 W01-R58-4062 138 W01-R58-4054 133 W01-R58-4060 136 W01-R58-4063 138 W01-R58-4074 139 W01-R58-4043 130 W01-R58-4037 137 W01-R58-4050 130 W01-R58-4051 131 W01-R58-4045 133 W01-R58-4055 134 W01-R58-4048 134 W01-R58-4044 136 W01-R58-4075 139 W01-R58-4047 135 W01-R58-4057 134 W01-R58-4038 136 W01-R58-4095 133 W01-R58-4056 134 W01-R58-4035 131 W01-R58-4081 130 W01-R58-4078 132 W01-R58-4070 132 W01-R58-4036 132 W01-R58-4059 135 W01-R58-4061 136 W01-R58-4073 137 W01-R58-4058 134
