    Goodyear Bellows NO. 578-91-3-301 Single Convoluted Air Spring 1B12-313 Easy Installation

    Ask Lasest Price
    Brand Name : GOODYEAR
    Model Number : 1B12-313
    Certification : ISO/TS16949:2009
    Price : USD79.9/PC-USD199.9/PC
    Delivery Time : 2-3 Working Days
    Payment Terms : T/T, Western Union, Paypal or Others
    Supply Ability : 1000PCS/Week
    • Product Details
    • Company Profile

    Goodyear Bellows NO. 578-91-3-301 Single Convoluted Air Spring 1B12-313 Easy Installation

    Easy Installation Goodyear Bellows NO. 578-91-3-301 Single Convoluted Air Spring 1B12-313

    Product Description:

    GOODYEAR AIR SPRING 1B12-306, 1B12-305, 1B12-301, 1B12-313, 1B12-322, and 1B12-300 are all single convolution models. These seven types of air springs all have the same BELLOWS NUMBER 578-91-3-301, but only the ways the top and botttom plates are connected differ. However, when these air springs are loading the machines, they have almost the same data sheet.

    Among these models, 1B12-301, 1B12-305, 1B12-306, and 1B12-322 have a bumper inside to limit the minimum stroke of the air spring.

    Features:

    Goodyear Part Number: 1B12-313

    Goodyear Part Number: 1B 12-313

    Goodyear Bellow Number: 578-91-3-301

    Goodyear Bellow Number: 578 91 3 301

    Goodyear Bellow Number: 578913301

    Contitech Bellow Number: 64596

    Contitech Part Number: FS 330-11 474

    Contitech Part Number: FS330-11 474

    Firestone Part Number: W01-358-7008

    Firestone Part Number: W01 358 7008

    Firestone Part Number: W013587008

    Technical Parameters:

    Top Plate Hole/Stud Qty3
    Top Plate Dia9.0
    Top Plate C to C Diameter6.2
    Bottom Plate Hole Stud Qyt2
    Bottom Plate Dia9.0
    Bottom Plate C to C Diameter6.20
    Bottom Plate AlignmentParallel
    BumperNo
    Min Height2.3
    Max Height7.2

    Support and Services:

    Goodyear Air Spring Technical Support and Service

    Goodyear Air Spring provides quality technical support and service to ensure the best performance of its products.

    Our team of experts is available 24/7 to answer your questions and provide technical assistance. Our customer service staff is also available to answer any questions and help with product selection.

    We offer installation and maintenance services for all our products, as well as on-site repair and replacement services. Our team is experienced in troubleshooting and resolving any issues related to Goodyear Air Spring products.

    We also offer comprehensive product warranties for all our products, including a limited lifetime warranty, to ensure our customers always have the best service and support.

    Packing and Shipping:

    Goodyear Air Spring Packaging and Shipping:

    • Each product is securely packaged in a corrugated cardboard box.
    • The box contains a detailed Instruction Manual.
    • The box is also labeled with an item number for easy identification.
    • Each box is shipped in a sealed, secure shipping container.
    • The shipping container is labeled with the item number, quantity, and the recipient's address.
