Air Suspension Kits With Cross Goodyear 2B9-200 Double Type Air
Super-Cushion 578-92-3-202
Product Description:
The GOODYEAR AIR SPRING series has ten different products, coded
2B9-200; 2B9-216; 2B9-210; 2B9-206; 2B9-201; 2B9-245; 2B9-244;
2B9-240; 2B9-230; and 2B9-225. These products all share the same
BELLOWS NUMBER (578-92-3-202), and while their top and bottom
plates differ, they all have compatible data sheets when being used
for equipment or vehicles.
The series’ 2B9-201; 2B9-206; 2B9-230; 2B9-244; and 2B9-245 models
all contain bumpers to limit their MIN stroke. In contrast, the
2B9-240 air spring has flange rings, and does not come with a cover
plate.
The remaining models in the series (2B9-200; 2B9-216; 2B9-210; and
2B9-225) come with crimped cover plates, making them much easier to
install with a machine.Overall, this GOODYEAR AIR SPRING series has
solutions for every application.
Features:
Replace OEM with AIRSUSTECH's air spring,if you have a different
brand or model number:
- GOODYEAR 2B9-200
- AUTOMANN ABSP2B12R-6910
- CONTI 64267
- FD 200-19 320
- DAYTON 354-6910
- DINA A-8127-19
- FIRESTONE 6910
- W013586910
- GRANNING 1371
- HDA PMABG-6910B
- HENDRICKSON 45843-3 & B-8768
- INT’L/NAVISTAR 554783C1
- LOAD GUARD SC2011
- MASA 227138412
- PREVOST 63-0173
- R&S TRUCK & BODY 1027405
- RIDEWELL 1003586910C
- S-4512-C
- SPRINGRIDE 2B9-492
- TAURUS AS218-6910
- TRIANGLE 4320
- TRP AS69100
- WATSON & CHALIN AS-0001
AIRSUSTECH's air spring replaces other kinds of OEMs, helping you
to save costs and time.
Technical Parameters:
| Parameters | Value |
|---|
| Cross Goodyear Bellows NO. | 578-92-3-202 |
| Cross Goodyear NO. | 2B9-200 2B9-216 2B9-210 2B9-206 2B9-201 2B9-245 2B9-244 2B9-240
2B9-230 2B9-225 |
| Cover Plate Diameter (Width) | 160 Mm |
| Warranty | One Year |
| Packaging | Strong Carton Packaging |
| The Working Stroke | MIN 3.2 Inches To MAX 10.8 Inches |
| Design Height | 6-7 Inches |
| Product Name | Air Ride Suspension, Suspension Air Springs |
| Operating Temperature | -40℃ To +70℃ |
| Pressure Range | 0.2-0.8 MPA |
Customization:
Customized Service for Suspension Air Springs
Brand Name: AIRSUSTECH
Model Number: 2B6910
Place of Origin: Guangzhou,China
Certification: ISO/TS16949:2009
Minimum Order Quantity: 2
Price: USD69-139.9/PC
Packaging Details: Strong Carton Box or as Customers Requirement
Delivery Time: 5-8 Working Days
Payment Terms: T/T, Western Union, Paypal or Others
Supply Ability: 1000PCS/Week
Packaging: Strong Carton Packaging
Cross Goodyear Bellows NO.: 578-92-3-202
Cross Goodyear Top Plate: ASA-92-8-016
Color: Black Rubber And White Zinc Iron Cover Plate
The Working Stroke: MIN 3.2 Inches To MAX 10.8 Inches
We offer customized services for Suspension Air Springs, such as
Air Struts, Rear Air Suspension, Air Ride Suspension, Coil Spring,
Shock Absorber, etc.
Support and Services:
Suspension Air Springs provide technical support and service for
our customers. We are committed to delivering a high quality
product with a variety of technical support services. Our team of
experienced technicians can provide assistance with installation,
troubleshooting, maintenance, and repair. We also offer customer
support for any questions or concerns related to our products.
We have a dedicated customer service team ready to help with any
issues that may arise. Our customer service representatives are
always available to answer questions and provide assistance. We
also provide online support and resources to help our customers
better understand and use our products.
Our technicians are highly trained and certified in the
installation and maintenance of Suspension Air Springs. We offer a
variety of maintenance services including inspections, repairs, and
replacement parts. We also offer a full range of diagnostic
services.
We strive to provide the best possible customer service and
technical support for all of our products. If you have any
questions or concerns about Suspension Air Springs, please don’t
hesitate to contact us. Our team is here to help.
