Replace 2B7-542 Goodyear Suspension Air Spring Easy Installation
579923525 Black Rubber
Product Description:
The AIRSUSTECH 2B7542 is an air spring produced by the factory
which is used for multiple applications. Not only are they used for
trucks and trailers, but also as vibration conveyors such as large
dryers, centrifugal separators, coordinate measuring tables and
machinery, and commercial washing machines.
The 2B7542 dual scroll airbag is capable of replacing the Goodyear 2B7-541
air spring. It is designed with the same technical parameters,
including the molded beads and flexible pieces at the end of the
bracket, which are connected by clamping the material between the
top plate and the bottom plate then adjusting it to the suitable
diameter. The Goodyear rubber bellows used on these is
579-92-3-525.
Features:
- Product Name: Suspension Air Springs
- Installation: Easy Installation
- Convolutions: 2
- Packaging: Strong Carton Packaging
- Warranty: 12 Months
- Product Type: Air Shocks, Air Bag Suspension Kits
Technical Parameters:
| Property | Description |
|---|
| Assembly Weight | 4.6 Lbs |
| Compressed height | 2.75 Inches |
| Load Capacity | According To The Sizes |
| Installation | Easy Installation |
| Pressure Range | 0.2-0.8 MPA |
| Cross Goodyear Top Plate | ASC-92-8-171 |
| Cover Plate Diameter (Width) | 132 Mm /5.31 Inches |
| Cross Goodyear Bellows NO. | 579-92-3-525 |
| Operating Temperature | -40℃ To +70℃ |
| Durability | High Durability |
| Air Suspension Components | Air Lift Air Springs, Air Suspension Components, Air Springs |
2B7-542 Goodyear Double Bellow Air Spring:
Goodyear #: 2B7-542
Bellow Type: Double
Goodyear Bellow #: 579-92-3-525
Top Plate Hole/Stud Qty: 2
Top Plate Dia: 5.03
Top Plate C to C Diameter: 2.75
Bottom Plate Hole Stud Qyt: 2
Bottom Plate Dia: 5.03
Bottom Plate C to C Diameter: 2.75
Bottom Plate Part #:ASB-92-6-058
Bottom Plate Alignment: Parallel
Bumper: Yes
Bracket:
Min Height: 3.3
Max Height: 9
